Z-105

Z-105 is the youngest and most affordable part of BETA-PAK packaging machine family. Although it has similar operational features, it can be used in applications with small capacity. It is the right machine type when it is required to focus on a single application instead of multiple applications. It is manufactured in required standards in terms of hygiene and the materials used. These are quiet and failure-free machines that require a single operator and minimum maintenance. Since all components, including main chassis and legs, are made of 304 quality stainless steel and sheet profiles, they have a long life even in the most challenging operating environments. We use the highest quality materials in pneumatic lines and implement the cutting-edge technology. Z 105 is a 3-phased, servo motor-controlled machine model with touch screen control panel that is controlled with electropneumatic system that allows you to make the required changes easily. All the equipment used in the machine have CE certificates. Thanks to its ease of use, the machine supports different molds as well.

Z-105
TECHNİCAL SPECIFICATION
Output6 - 8 cycles/min.
Film Widths200mm - 360mm
Film Thickness80 mic. - 700 mic
Bottom Film(PA+PE) / (PVC+PE) / (PET+PE)
Top Film(PA+PE)
Step80mm - 240mm
Shape Depthmax. 90mm
Machine Lengthmax. 5.000 mm
Z-105
USAGE AREAS
